| Place of Origin | Zhengzhou China |
| Trademark | BOSDI |
| Minimum Order | 5 Pcs |
| Delivery Time | 3-5 days |
| Payment Terms | T/T, L/C, Western Union, MoneyGram, Paypal |
| Supply Ability | 350,000 Pcs/ year |
| Price | Negotiable |
| Package | Carton, Plastic drum/bag, pallet, wooden box |
Manufacturing process classification
※. Sintered diamond saw blade: It is made of cold pressing sintering and hot pressing sintering. Features: Stable quality, high sharpness.
※. Welding of diamond saw blade: there are two types: high-frequency welding and laser welding. The high-frequency welding is used to weld the cutter head and the base through the high-temperature melting medium, and the laser welding is used to melt the contact edge of the cutter head and the base through the high-temperature laser beam to form a metallurgical bond. Features: high strength, abrasion resistance, long service life.
※. Electroplated diamond saw blade: it is used to attach the cutter head powder to the substrate by electroplating. Features: fast cutting speed, short service life.
Appearance classification
※. Continuous edge saw blade: continuous sawtooth diamond saw blade is generally made by sintering. Bronze bond is commonly used as the base matrix material. When cutting, water must be added to ensure the cutting effect. Besides, laser can be used to cut the gap.
※. Blade type saw blade: sawtooth is broken, cutting speed is fast, suitable for dry and wet cutting methods.
※. Turbine saw blade: combining the advantages of the first two items, the sawtooth continuously presents turbine like uniform convex concave, which improves the cutting speed and increases the service life.
Different kinds of diamond saw blades are selected for different materials, and different powder formulations are suitable for the characteristics of different materials, which has a direct impact on the quality, effect, qualification rate, cost and benefit of material products.
The factors that affect the efficiency and life of diamond circular saw blade are sawing process parameters, diamond particle size, concentration, bond hardness, feed speed, etc.
Road cutting pieces are widely used in our daily life and are usually used to repair roads. It is mainly used for cutting concrete, asphalt, slate, ceramics, wall trough, limestone, sandstone, granite, etc., with stable quality and high cutting efficiency
※ . It is used to cut and pour reinforced concrete, asphalt, cement pavement, stone, etc. for more than 24 hours, and to renovate the old asphalt road and cement pavement.
※ . By using prealloyed powder as matrix, the purpose of reducing the ineffective shedding of diamond and maximizing its use effect is achieved. It can cut 1500-3000m.
※ . Water cutting, suitable for road cutting machine.
※ . The laser welding process is adopted, and the cutter head is firmly combined to prevent the teeth from falling off.
※ . For cutting concrete and brick walls
Diamond saw blade cutting wheel
Details Information: Laser welding and high-frequency welding
| Item | OD | Blade length | Blade thickness | Blade height | ID |
| No. | mm | mm | mm | mm | mm |
| BSD-8541 | 150 | 40 | 2.5~3.2 | 10~12 | 20 |
| BSD-8542 | 250 | 40 | 2.6~3.2 | 10~12 | 20 |
| BSD-8543 | 350 | 40 | 2.8~3.4 | 10~15 | 25.4 |
| BSD-8544 | 400 | 40 | 3.0~3.8 | 10~21 | 25.4 |
| BSD-8545 | 500 | 40 | 4.2~4.8 | 10~13.5 | 50 |
| BSD-8546 | 600 | 40 | 4.5~5.0 | 10~15 | 50 |
| BSD-8547 | 700 | 40 | 5 | 10~15 | 70 |
| BSD-8548 | 800 | 40 | 4.5 | 10~15 | 100 |
| BSD-8549 | 900 | 24 | 4.5 | 12~14 | 120 |
| BSD-854A | 1000 | 24 | 6.5 | 12~14 | 150 |
| BSD-854B | 1200 | 24 | 6.5 | 12~14 | 200 |
We can customize according to customer requirements. In addition to road saw blades, we also have saw blades for cutting cement, asphalt, granite, marble, concrete, etc. We welcome your order and email consultation
