resin grinding wheel

Place of Origin  Zhengzhou China
Trademark BOSDI
Minimum Order   5000 Pcs
Delivery Time 15 days
Payment Terms T/T, L/C, Western Union, MoneyGram, Paypal
Supply Ability 5,000 tons / year
Price Nigotiable
Package Carton, Plastic drum/bag, Metal bucket
Add To Cart Successfully
OK
  • Description
  • Application
  • Product Data
  • Send Email

Product Description

1. The reinforced resin grinding wheel is made of high-strength glass fiber mesh, abrasive, phenolic resin liquid and resin powder mixed in a certain proportion, and then pressed, shaped and sintered. The structure is simple, the chemical reaction is complex, and the requirements for production temperature, moderation, equipment, process and climate are extremely high. Every detail is the key to control product quality.

2. Abrasives: brown corundum, white corundum, silicon carbide, single crystal corundum, zircon corundum, ceramic corundum, gypsum accessories, etc. We choose high-quality products regardless of the raw materials.

3. Resin glass fiber mesh: we use reinforced glass fiber mesh

4. Binder: Special binders are imported to ensure the strength and reduce dust, so that the products produced are not easy to deform, crack and produce peculiar smell during the working process, reduce dust and noise, and increase hand comfort and service life.

BOSDI resin cutting pieces are made of high-quality abrasives and binders, combined with advanced production processes and fully automatic curing tunnel kilns, so that our products have outstanding advantages in performance comparison of similar products: tensile strength, impact resistance, high quality, high sharpness, good hand feel, no workpiece burns, no burrs after grinding.

Product Application

Ultra thin series products are applicable to cutting precious metals, hard alloys, automobile cables, pen tip gaps, metal tube slits, metal and non-metallic cut-off, etc. Products can be customized according to customer needs

※ core advantages:super sharpness.

※ main raw materials: single crystal aluminium, zirconium, Iridium plated white corundum

※ key technologies: Stable performance, super sharp, Cutting without burr

Suitable for grinding stainless steel, angle steel, cast iron, hollow steel, deformed steel, round steel, square pipe, galvanized sheet, tungsten steel, rail, box and other metal materials. Sharp products can greatly improve your cutting efficiency and save your costs.

Type T41: Cutting wheel

Model Size Size Speed Application
No. mm inch m/s for
BSD-45631 100x1.2x16 4”x1/25”x5/8” 80 Metal,Steel,Stainless steel,hard alloy,cast iron, deformed bar,tungsten steel, Titanium alloy and so on
BSD-45632 115x1.2x22 4.5”x1/25”x7/8”
BSD-45633 125x1.2x22 5”x1/25”x7/8”
BSD-45634 150x1.6x22 6”x1/16”x7/8”
BSD-45635 180x1.6x22 7”x1/16”x7/8”
BSD-45636 230x1.9x22 9”x1/12”x7/8”

It is widely used in metal processing, stainless steel processing, plant construction, automobile industry, shipbuilding industry, aviation industry and other fields.

Type T41: Mini cutting wheel

Model Size Size Speed Application
No. mm inch m/s for
BSD-45641 50x2x10 2”x1/12”x2/5” 80 Metal,Steel,Stainless steel,hard alloy,cast iron, rubber tire and so on
BSD-45642 70x2x10 2”x1/12”x2/5”

Mini cutting wheel It is used to polish metal and nonmetal, repair tire and metal inner edge and so on.

Type T41: Ultra thin cutting wheel

Model Size(ODxThickxID) Size Speed Application
No. mm inch m/s for
BSD-45651 100x0.5~1.0x16 4”x1/50”x5/8” 80 Metal,Steel,Stainless steel,hard alloy,cast iron, deformed bar,tungsten steel, Titanium alloy and so on
BSD-45652 115x0.5~1.0x22 4.5”x1/50”x7/8”
BSD-45653 125x0.5~1.0x22 5”x1/50”x7/8”
BSD-45654 150x0.5~1.0x20 6”x1/50”x7/8”
BSD-45655 180x0.5~1.0x25 7”x1/50”x7/8”
BSD-45656 200x0.5~1.0x32 9”x1/50”x7/8”

We can do the thickness from 0.5 to 1.0mm,we also customize products of other specifications
